Municipal pump stations play a crucial role in managing wastewater and stormwater effectively. These facilities, equipped with either wet or dry wells, ensure the safe transport and processing of fluids within urban environments. Understanding the differences between these two types of pump stations is essential for effective fluid management. This knowledge helps municipalities select the appropriate system to meet their specific needs, ensuring efficient operation and minimizing environmental impact.

What is a pump station?

Pump stations are the (mostly) hidden heroes of fluid management. To strip them back to their most basic form, a pump station is a tank, container, set that houses pumping equipment in a contained way to meet the demands of the environment. They are part of a wider fluid control system and become the receivers of the output from any properties, buildings, environmental areas where fluid needs to be held, processed and then redistributed. As storm and wastewater management systems, pump stations are used to mediate issues with gravity that would otherwise disrupt or prevent the movement of fluids from one place to another. Every packaged pump station is designed to meet the demands of its environment and will vary in terms of construction material and the interior contents e.g., accessories and pumps.

Pump Station Types: Wet Wells Vs Dry Wells

Dry wells and wet wells are two of the most common pumping station types. And while they both play critical roles in sewage collection networks, they are different in a number of ways.

-Wet Well

Almost all wastewater pump stations have a wet well (also called a sump well). This underground pit collects sewage from the incoming sewer and pumps it to a gravity manhole where it is transported to the treatment plant. However, wet wells are notorious for clogging with wipes and other debris that can be difficult to remove. This is why it is crucial to keep your grinder pumps running & the level control system clear of debris so that they can do their job effectively.

-Dry Well

In dry well pumping stations, sewage flows into a collector and then passes through a dividing chamber with a self-cleaning separator of coarse solids before entering the retention module. In traditional sewage pumping stations, pumps and pipework are installed in a dry well which also houses electrical and control equipment. This configuration enables safe entry and operation maintenance of pumps and pipework. Some authorities prefer dry well installations over wet wells for large, very deep and critical pumping stations as they can provide easier access to pumps for condition monitoring, inspection and in-situ maintenance. This option also protects electrical equipment from flooding.

Importance of Municipal Pump Stations

– Effective Fluid Management:

Ensure safe transport and processing of wastewater and stormwater.

– Flood Prevention:

Mitigate flooding risks in urban areas.

– Environmental Protection:

Prevent contamination of water resources and ecosystems.

– Adaptability:

Utilize wet and dry wells to meet various operational conditions.

– Public Health Safety:

Reduce risks of sanitary sewer overflows, protecting community health.

– Technological Advancements:

Enhance efficiency and sustainability in urban infrastructure.

– Community Support:

Maintain clean water resources, crucial for the overall well-being of residents.

Safety & Maintenance

Wet wells are typically found at sewage pump stations and are the places where sewage is collected, stored and lifted through the sewer system. They are also the most hazardous areas. Sewage containing dangerous chemicals such as methane and hydrogen sulfide can build up inside of a wet well. If a person enters a wet well without the proper confined space entry method, they can become seriously ill. A dry well, on the other hand, is a separate part of a pump station that houses electrical and control equipment. This type of pumping station is less dangerous because it doesn’t directly expose a person to the sewer atmosphere.

Performing routine maintenance on wet wells and lift stations reduces the risk of sanitary sewer overflow (SSO), which can have serious consequences for the environment, residents and the surrounding community. By tracking run times, monitoring pressure, keeping floats and check valves clean, and conducting visual inspections of the site, operators can improve reliability and minimize the risk of a wet well or lift station overflowing into a wastewater treatment plant.

Conclusion

The choice between wet well and dry well pump stations will largely depend on an individual’s particular need or requirement. Wet wells are great for applications that require large amounts of water, while dry wells are more suitable for situations where a smaller amount of liquid is needed. In any case, careful consideration should be taken in order to identify which type of system is best suited for a particular application. With this knowledge in hand, one can be sure to choose the best solution for their project.
