In modern industrial and commercial applications, pumps are widely used in many fields, from water supply systems to chemical processes to sewage treatment. One of the core components of the pump, the pump casing, plays a vital role. More than just a simple housing, the pump casing carries the entire pump system in operation, influencing fluid flow and pressure changes. Understanding the function and characteristics of this indispensable component, the pump casing is essential to understanding the working principle and performance of the pump.

What is a pump casing?

Casing in centrifugal pump serves to seal off the inside of the pump to the atmosphere to prevent leakage and retain pressure. In the case of centrifugal pumps, they surround the pump rotor which transmits energy to the fluid handled via the impeller mounted on the rotating shaft.

The term casing is generally used to describe the component that contains the pump. In practice a pump’s casing has five functions:

1.It will Provide pressure containment.

2.Incorporate the collector, either as an integral part of the casing or as a separate piece.

3.Permit rotor installation and removal.

4.Support the pump or provide a structural connection to the pump’s support.

5.Maintain alignment of the pump and its rotor under the action of pressure and reasonable piping loads.

Importance of the Centrifugal Pump Casing

-Holding the internal parts

The pump casing provides a space to hold and support the internal parts, including impellers, bearings, seals, etc. The pump casing provides a space to hold and support the internal parts. These parts are mounted inside the pump casing to ensure the solidity and reliability of the pump.

-Directs the fluid

The design of the pump casing can affect how the fluid flows and the distribution of the flow rate. Typically, the design of the inside of the pump casing directs the fluid entering the pump so that it flows smoothly through the impeller is accelerated, and then discharged through the outlet port.

-Increased pressure

The shape and construction of a centrifugal pump’s casing can help increase the pressure of the fluid. The shape of the pump casing compresses and accelerates the fluid as it passes through the pump casing and into the impeller, thereby increasing the pressure of the fluid and allowing it to flow smoothly out of the pump body.

-Protecting internal components

The pump casing also serves to protect internal components from external environmental factors that can cause damage to the pump’s internals. For example, it prevents impurities and particles such as corrosive liquids, water, etc. from entering the pump, and protects key parts such as impellers and bearings.

-Connection ports

Pump casings typically have inlet and outlet ports and connection ports for connecting piping systems and other equipment. These connection ports allow the pump to be easily connected to piping systems and other equipment for fluid transfer.

The pump casing of a centrifugal pump plays a vital role in the operation of the pump, which not only provides support and protects the internal parts, but also guides the fluid, increases the pressure, and connects with other equipment through the connection ports, thus ensuring the normal operation and efficient work of the centrifugal pump.

Types of casing in a centrifugal pump

1.Vortex casing

Vortex casing is a casing in which circular chamber is provided between the casing and the impeller. Vortex casing is helpful to increase pump efficiency by reducing eddies formation to a considerable extent.

2.Casing With Guided Blades

In the casing with guided blades the impeller is surrounded by series of guide blades.

The guide blades are mounted on a ring which is called as diffuser.

3. Ram Pump Casings

Ram pump casings are the housings used in ram pumps and are usually made of metal. They house and support the plunger, seals, and other internal components, and are designed to control and direct the flow of liquid through the interior of the pump casing.

4.Screw Pump Casings

Screw pump casings are housings used for screw pumps and are typically made of metal or alloy materials. They house the screw and control and direct the flow of liquid through the design of the pump casing, resulting in increased pressure and flow transfer.

5. Diaphragm Pump Housings

Diaphragm pump housings are designed for diaphragm pumps and are typically made of metal or plastic. They house the diaphragm, pump head, and other internal components, controlling and directing the flow of liquid through the interior of the pump housing, allowing for suction and discharge of liquid.

6. Vacuum Pump Casings

Vacuum pump casings are used for vacuum pumps and are usually made of metal. They house the rotary vane, impeller, or other internal components and are designed to control and direct the flow of gases through the interior of the pump casing to create and maintain a vacuum.

7. Self-Priming Pump Casings

Self-priming pump casings are the housings used for self-priming pumps and are usually made of metal or plastic. They house impellers, seals, and other internal components, designed to control and direct the flow of liquid through the interior of the pump casing for self-priming and dewatering functions.

8.Volute casing

It is a spiral type in which area of flow increase gradually. The increase in area of flow decreases the velocity of flow. Decrease in velocity increases pressure of water flowing through the casing.

-Volute casing is the most common type of casing

The volute casing pump is the most common type of centrifugal pump. Its characteristic feature is the volute-shaped pump casing which is typical for single-stage centrifugal pumps.

Difference Between Pump Casing and Worm Casing

The pump casing of a centrifugal pump is mainly used to house and support the rotor and bearings inside, while the worm casing is mainly used to house and hold the impeller, and through its special design directs the fluid into the impeller and accelerates the rotation.

Features	Pump Casing	Worm Casing
Definition	The housing of the pump houses and supports key components such as rotors, impellers and bearings inside.	The external housing of the impeller
Material	It is usually made of metal or alloy material.	Made of metal or plastic material.
Function	Hold and support internal components, Directs the fluid to the impeller.	Holds and secures impeller, directs fluid into impeller and accelerates rotation
Fluid Guide	Affects the way fluids flow and the distribution of flow velocity.	Directs the fluid into the impeller and changes its flow rate and direction.
Connection	It affects the flow pattern and velocity distribution of the fluid.	Usually attached to the pump casing.
Key Influencing Factors	performance and efficiency, the way the fluid flows.	Rotational speed of the impeller, design of the inner wall of the worm gear.

Advantages And Disadvantages Of Pump Casing

-Advantages Of Pump Casing

-Provide structural support

-Protects internal components

-Provide connection ports

-Adaptable

-Disadvantages Of Pump Casing

-Higher manufacturing costs

-Difficult to maintain

-Higher weight

-It may affect the pump performance

As a key component of centrifugal pumps, the pump casing has important functions and roles, but its advantages and disadvantages need to be weighed in the selection and design to ensure the normal operation and long-term stability of the pump.

conclusion

The centrifugal pump casing is a critical component that directly influences the performance, efficiency, and longevity of the pump. It serves multiple essential functions, including providing structural support, directing fluid flow, increasing pressure, and protecting internal components from environmental factors. The design and material of the casing play a significant role in ensuring optimal operation and stability over time. Therefore, selecting the appropriate casing is vital for achieving reliable performance and maintaining the overall effectiveness of centrifugal pumps in various applications. Understanding the characteristics and importance of the pump casing is essential for engineers and technicians to ensure successful pump operation and longevity.
